Novacord SMPTE-311M Hybrid High Flex Camera Cable
Catch the best moments!
Order
STANDARD SMPTE 311M
It is used in professional video productions for simultaneous transmission of energy, video, audio and control signals and is intended to interconnect Camera Units and Base Stations in conjunction with the Connector Interface Standard. It is suitable for all new digital camera systems of well-known manufacturers.

SMPTE-311M Hybrid Camera cable PVC

Professional Hybrid HD Camera Cable with flexible soft jacket. This cable 2SM 9/125 + 4 x AWG20 + 2 x AWG24 acc. to SMPTE 311M-Standard contains Single-Mode Optical Fibres, Auxiliary- and Signal Conductors.

SMPTE-311M Hybrid Camera cable FRNC-C
Professional Hybrid HD Camera Cable with flexible soft jacket. This cable 2SM 9/125 + 4 x AWG20 + 2 x AWG24 acc. to SMPTE 311M-Standard contains Single-Mode Optical Fibres, Auxiliary- and Signal Conductors. IEC-60322-3-24
Construction
Auxiliary Conductors AWG20 (4 x 0.6 mm2 )
Conductor: tinned stranded copper wires, 19 x 0.20 mm, diameter 1.0 mm
Insulation: HDPE, diameter 1.5 mm
Strength Member AWG16 (1 x 1.22 mm2)
Conductor: galvanized steel wires, diameter 1.6 mm
Insulation: HDPE, diameter 2.1 mm.
Braid sheild
Copper wire braid, tinned 95% opt. coverage, diameter 5.9 mm
Signal Conductors AWG24 (2 x 0.22 mm2 )
Conductor: tinned stranded copper wires, 7 x 0.20 mm, diameter 0.6 mm
Insulation: HDPE, diameter 1.1 mm
Fibre Optic Single Mode (2 x 9/125µ)
Mode field diameter: at 1310 nm, diameter 9.5 µm ± 1 µm
Cladding diameter: diameter 125 µm ± 1 µm
Coating material: UV-cross-linked Acrylate, diameter 245 µm
Buffer material: diameter 0.9 µm ± 0.05 µm, Thermoplastic

Properties Novacord SMPTE-311M
Auxiliary Conductors
AWG20 (4 x 0.6 mm 2 )
  • DC resistance ≤ 35.3 Ω/km
  • Loop resistance ≤ 43 Ω/km
  • Insulation resistance ≥ 104 MΩ*km
  • Test voltage 1750V AC rms
  • Operating voltage ≤ 300V AC rms
Signal Conductors
AWG24 (2 x 0.22 mm2 )
  • DC resistance ≤ 97.5 Ω/km
  • Loop resistance ≤ 184 Ω/km
  • Insulation resistance ≥ 104 MΩ*km
  • Test voltage 1750V AC rms
  • Operating voltage ≤ 300V AC rms
Fibre Optic Single Mode
(2 x 9/125µ)
  • Cut-off wavelength 1100 – 1350 nm
  • Attenuation 0.5 dB
  • Dispersion 3.5 ps/nm*km
