NOVACORD MULTICORE CABLE

Type:

Diameter

Jacket

Triaxial camera cables are used simultaneous transmission of energy and multiplex image signals between camera head and control system for SDI and HD-SD, structure: 1.4/6.5 mm silvered copper, insulation PE, inner screen - silvered copper, insulation PE, outer screen - copper braid, FRNC-C/LSZH jacke

Applications

Live sound & touring – stage boxes, audio snakes, patch systems
Recording studios – balanced audio routing, multi-channel interconnects
Broadcast & media production – multi-channel signal distribution
Theater & installations – fixed audio infrastructure
Event venues & conference halls – multi-line audio wiring
Rack & patchbay wiring – compact and organized cabling solutions

Key Features

Architects, designers, and environmentalists are partnering to design the perfect spaces for a sustainable future.

Pure copper conductors

high-purity copper conductors for stable signal transmission
Advanced shielding

suitable for balanced microphone and line-level signals
Flexible, easy-to-install jacket

suitable for in-wall, rack, or open-run applications
Low noise

clean, low-noise signal transfer on multi-channel systems
Available in multiple gauges

to match power and distance requirements
PVC outer sheath

designed for stage, studio, rack, or trunk use

TECHICAL SPECIFICATIONS

Items:	Cross Sec. Area	Strands	Diameter of insulation 1	Diameter of insulation 2	Overall diameter
Triax 8	1.78 mm2	7/0.32 mm	4.5 mm	6.6 mm	8.9 mm
Triax 11	1.54 mm2	1/1.4 mm	6.5 mm	8.6 mm	11 mm
Triax 14	3.8 mm2	1/2.2 mm	9.7 mm	11.9 mm	14.5 mm

DATA SHEETS

PRODUCT

Download datasheet Triax 8 FRNC-C

Download datasheet
Triax 11 FRNC-C

Download datasheet Triax 14 FRNC-C

Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.

Conductor:

This cable uses OFC (Oxygen-Free Copper) conductors, ensuring superior signal transmission and long-term reliability. Oxygen-free copper contains a significantly lower level of oxygen impurities compared to standard copper, resulting in improved conductivity and reduced signal loss over long distances.

Insulation protects the copper conductors from damage, prevents short circuits, and keeps the audio signal clean. Color-coded layers (red/black) ensure correct polarity and easy installation. Depending on the version (PVC or FRNC-C), insulation also provides added flexibility, durability, and fire safety.

The cable features a durable, flexible outer jacket that protects the conductors from mechanical stress, abrasion, and bending. Its smooth surface ensures easy installation, while the material provides long-lasting reliability. Available in a black finish for a clean, professional look; FRNC-C versions offer added flame-retardant and low-smoke safety.

Insulation:

Jacket:

Conductors

Insulation

Jacket

STRUCTURE OF CABLES

Learn more

PVC

FRNC-C

PVC - Polyvinyl Chloride (PVC) is the most common jacket material used in cabling today. PVC is a cost-effective option yet still flexible and rugged enough for many work sites.

FRNC-C - flame-retardant and halogen-free for permanent indoor installationsand complies with the European CPR fire classification Dca.

Certification:

VDE 0472 part 804 class B
IEC 60332-1

Certification:

IEC 60332-3-24
CPR Class: Dca
