NOVACORD SPEAKER CABLES 2xXX

Type: 2 conductors

Cross section:

Screen:

Jacket

2-conductor speaker cable is designed to deliver clear, consistent audio performance in home, commercial, and professional installations. Featuring high-quality copper conductors and durable insulation, this cable ensures low signal loss and stable sound transmission over long distances.

Applications

Home theater and Hi-Fi systems
Commercial audio installations
Sound reinforcement in halls, conference rooms, and venues
Background music systems and distributed audio

Key Features

Architects, designers, and environmentalists are partnering to design the perfect spaces for a sustainable future.

Pure copper conductors

for optimal signal transfer and reduced resistance
Two-core design (2C)

ideal for standard speaker connections
Flexible, easy-to-install jacket

suitable for in-wall, rack, or open-run applications
Low noise & interference

thanks to precision-twisted conductors
Available in multiple gauges

to match power and distance requirements
Polarity-marked insulation

for quick, error-free hookup

TECHICAL SPECIFICATIONS

Items:	Cross Sec. Area	Strands	Diameter of insulation	Overall diameter	DC Resistance
Speaker 2x1.5	1.5 mm²	22/0.3 mm	2.4 mm	6.2 mm	≤ 11.6 Ω/km
Speaker 2x2.5	2.5 mm²	80/0.2 mm	3.05 mm	8.0 mm	≤ 7 Ω/km
Speaker 2x4	4 mm²	56/0.3 mm	3.85 mm	9.1 mm	≤ 4.4 Ω/km
Speaker 2x6	6 mm²	84/0.3 mm	4.6 mm	11.2 mm	≤ 3.1 Ω/km
Speaker 2x8	8 mm²	112/0.3 mm	5.0 mm	13.0 mm	≤ 2.3 Ω/km
Speaker 2x10	10 mm²	140/0.3 mm	5.4 mm	15.0 mm	≤ 1.9 Ω/km

DATA SHEETS

PRODUCT

Download datasheet Speaker 2x1,5 PVC

Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.

DATA SHEETS

PRODUCT

Download datasheet Speaker 2x1,5 FRNC-C

Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.

Conductor:

This cable uses OFC (Oxygen-Free Copper) conductors, ensuring superior signal transmission and long-term reliability. Oxygen-free copper contains a significantly lower level of oxygen impurities compared to standard copper, resulting in improved conductivity and reduced signal loss over long distances.

Insulation protects the copper conductors from damage, prevents short circuits, and keeps the audio signal clean. Color-coded layers (red/black) ensure correct polarity and easy installation. Depending on the version (PVC or FRNC-C), insulation also provides added flexibility, durability, and fire safety.

The cable features a durable, flexible outer jacket that protects the conductors from mechanical stress, abrasion, and bending. Its smooth surface ensures easy installation, while the material provides long-lasting reliability. Available in a black finish for a clean, professional look; FRNC-C versions offer added flame-retardant and low-smoke safety.

Insulation:

Jacket:

Conductors

Insulation

Jacket

STRUCTURE OF CABLES

Learn more

PVC

FRNC-C

PVC - Polyvinyl Chloride (PVC) is the most common jacket material used in cabling today. PVC is a cost-effective option yet still flexible and rugged enough for many work sites.

FRNC-C - flame-retardant and halogen-free for permanent indoor installationsand complies with the European CPR fire classification Dca.

Certification:

VDE 0472 part 804 class B
IEC 60332-1

Certification:

IEC 60332-3-24
CPR Class: Dca

PRODUCT PICTURES
