NOVACORD SPEAKER 2x2.5
The purpose of a loudspeaker cable is a wire used for electrical
connections between the amplifier sources and the
loudspeaker system, in which transmission is carried out
using a low-voltage electric current.
connections between the amplifier sources and the
loudspeaker system, in which transmission is carried out
using a low-voltage electric current.
Oxygen Free Copper 99,9%
One of the best conductors is oxygen-free copper, which is the standard for speaker wires and the best choice.
Flexible construction
The cable design and jacket materials are designed for convenient use and mounting of equipment
Pure signal transmission
The electrical parameters of the cable create conditions for better signal transmission
Description
The speaker cable is designed for use in professional broadcasting systems, speakers and loudspeakers for the transmission of analogue audio signals. Suitable for recording studios, rehearsal studios, concert and presentation venues. Сable is available in two versions of outer jackets: PVC and FRNC-C
Speaker 2x2.5 PVC
Speaker 2x2.5 FRNC-C
Flexiable jacket
Flame retardant and non corrosive jacket
Conductor:
Cross Sec. Area:
No. of Cores:
Material:
Type of conductor:
Strands:
No. of Cores:
Material:
Type of conductor:
Strands:
2.5 mm2, Ø 1.6 mm
2 cores
OFC
Stranded
22/0.3±0.008 mm
2 cores
OFC
Stranded
22/0.3±0.008 mm
Insulation:
Material:
Type of conductor:
Color:
Type of conductor:
Color:
PVC / LSHF-FR
2.4 ±0.1 mm
Black, Red
2.4 ±0.1 mm
Black, Red
Jacket:
Material:
Diameter:
Color:
Diameter:
Color:
PVC / FRNC-C
6.2±0.2 mm, AWG16
Black, RAL9005
6.2±0.2 mm, AWG16
Black, RAL9005
Conductors
Insulation
Jacket
Structure:
Electrical properties
DC Resistance
≤ 7 Ω/km
Insulation resistance
> 200 MΩ/km
Operating voltage
50/75V AC/DC
Mechanical properties
Bending radius without load
33 mm / 4xD
Bending radius without load
65 mm / 8xD
Temperature range
-30°C to +70°C
PVC
FRNC-C
PVC - Polyvinyl Chloride (PVC) is the most common jacket material used in cabling today. PVC is a cost-effective option yet still flexible and rugged enough for many work sites.
FRNC-C - flame-retardant and halogen-free for permanent indoor installationsand complies with the European CPR fire classification Dca.
Certification:
VDE 0472 part 804 class B
IEC 60332-1
IEC 60332-1
Certification:
IEC 60332-3-24
CPR Class: Dca
CPR Class: Dca
