NOVACORD MICROPHONE CABLE
Type:
Cross section:
No. of Cores
Jacket
Contact us
Microphone cables deliver clean, low-noise audio transmission thanks to precision-twisted conductors and advanced shielding. Designed for studio, stage, and broadcast use, they offer reliable performance, flexibility, and durability in any professional environment.

Applications
  • Professional recording studios
  • Broadcast studios and OB-vans
  • Live sound reinforcement (stages, concerts, touring)
  • Theatre and performance venues
  • Conference rooms, boardrooms, and corporate AV setups

Key Features

Architects, designers, and environmentalists are partnering to design the perfect spaces for a sustainable future.

  • Pure copper conductors

    deliver maximum signal integrity, extended frequency response, and consistent performance

  • Advanced double shielding

    provides superior protection against external noise

  • Flexible, easy-to-install jacket

    suitable for in-wall, rack, or open-run applications

  • Low noise & interference

    thanks to precision-twisted conductors

  • Available in multiple gauges

    to match power and distance requirements

  • Polarity-marked insulation

    for quick, error-free hookup

TECHICAL SPECIFICATIONS


Items:

Cross Sec. Area

Strands

Diameter of insulation

Overall diameter

DC Resistance

Micro 22

0.22 mm2

28/0.1 mm

1.3 mm

6 mm

≤ 78.5 Ω/km

Micro 22 Slim

0.22 mm2

7/0.2 mm

1.02 mm

3.1 mm

≤ 88.5 Ω/km

Micro 2x0.30

0.30 mm2

60/0.08 mm

1.75 mm

6 mm

≤ 65 Ω/km

Micro 2x0.50

0.50 mm2

16/0.2 mm

2.0 mm

5.7 mm

≤ 40 Ω/km

Star Quad 4x0.15






Star Quad 4x0.20

0.20 mm2

40/0.08 mm

1.38 mm

6 mm

≤ 88.5 Ω/km

Star Quad 4x0.50






DATA SHEETS
PRODUCT
Download datasheet Micro 22 PVC
Download datasheet Micro 22 Slim PVC
Download datasheet Micro 2x0.30 PVC
Download datasheet Micro 2x0.50 PVC
Download datasheet Star Quad 4x0.15 PVC
Download datasheet
Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.
DATA SHEETS
PRODUCT
Download datasheet Micro 22 FRNC-C
Download datasheet Micro 22 Slim FRNC-C
Download datasheet Micro 2x0.30 FRNC-C
Download datasheet Micro 2x0.50 FRNC-C
Download datasheet


Star Quad 4x0.15 FRNC-C
Download datasheet
Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.

Star Quad 4x0.20 FRNC-C
Conductor:
This cable uses OFC (Oxygen-Free Copper) conductors, ensuring superior signal transmission and long-term reliability. Oxygen-free copper contains a significantly lower level of oxygen impurities compared to standard copper, resulting in improved conductivity and reduced signal loss over long distances.
Insulation protects the copper conductors from damage, prevents short circuits, and keeps the audio signal clean. Color-coded layers (red/black) ensure correct polarity and easy installation. Depending on the version (PVC or FRNC-C), insulation also provides added flexibility, durability, and fire safety.
The cable features a durable, flexible outer jacket that protects the conductors from mechanical stress, abrasion, and bending. Its smooth surface ensures easy installation, while the material provides long-lasting reliability. Available in a black finish for a clean, professional look; FRNC-C versions offer added flame-retardant and low-smoke safety.
Insulation:
Jacket:
Conductors
Insulation
Jacket
STRUCTURE OF CABLES
Learn more
PVC
FRNC-C
PVC - Polyvinyl Chloride (PVC) is the most common jacket material used in cabling today. PVC is a cost-effective option yet still flexible and rugged enough for many work sites.
FRNC-C - flame-retardant and halogen-free for permanent indoor installationsand complies with the European CPR fire classification Dca.
Certification:
VDE 0472 part 804 class B
IEC 60332-1
Certification:
IEC 60332-3-24
CPR Class: Dca
