NOVACORD MULTICORE DMX CABLE
Type:
Pairs:
Jacket
Contact us
DMX MultiCore cables are engineered for digital lighting control systems requiring stable RS-485 signal transmission over long distances.
Available in PVC and FRNC-C versions, they feature precise impedance control, robust shielding, and conductor constructions optimized for reliability in demanding lighting networks.

These cables allow combining multiple DMX universes in a single jacket, simplifying routing and reducing cable clutter in stage, touring, and installation setups. FRNC-C versions meet increased safety requirements for public and indoor environments.

Applications
  • Professional lighting control – DMX512/1990 and DMX512-A networks
  • Stage and touring – multi-universe cables for lighting rigs
  • Theaters, concert halls, arenas – fixed DMX infrastructure
  • Media production & TV studios – stable digital lighting control lines
  • Architectural lighting – multi-channel DMX control systems
  • Installations with fire-safety requirements – FRNC-C versions

Key Features

Architects, designers, and environmentalists are partnering to design the perfect spaces for a sustainable future.

  • Pure copper conductors

    high-purity copper conductors for stable signal transmission

  • Advanced shielding

    ensures strong EMI/RFI protection for digital signals

  • Flexible, easy-to-install jacket

    suitable for in-wall, rack, or open-run applications

  • Low noise

    clean, low-noise signal transfer on multi-channel systems

  • Available in multiple gauges

    to match power and distance requirements

  • FRNC-C options

    for increased fire resistance and low-smoke performance

TECHICAL SPECIFICATIONS


Items:

Cross Sec. Area

Strands

Diameter of insulation

Overall diameter

DC Resistance

MultiCore 2P 26/7 DMX

0.14 mm2

7/0.48 mm

1.2 mm

7 mm

≤ 288 Ω/km

MultiCore 2P 23/1 DMX

0.26 mm2

1/0.56 mm

1.4 mm

8.3 mm

≤ 165 Ω/km

MultiCore 2P 24/7 DMX

0.22 mm2

7/0.60 mm

1.4 mm

9.6 mm

≤ 175 Ω/km

MultiCore 4P 26/7 DMX

0.14 mm2

7/0.48 mm

1.2 mm

11.9 mm

≤ 288 Ω/km

MultiCore 4P 23/1 DMX

0.26 mm2

1/0.56 mm

1.4 mm

11.1 mm

≤ 165 Ω/km

MultiCore 4P 24/7 DMX

0.22 mm2

7/0.60 mm

1.4 mm

11.4 mm

≤ 175 Ω/km

MultiCore 8P 26/7 DMX

0.14 mm2

7/0.48 mm

1.2 mm

16 mm

≤ 288 Ω/km

MultiCore 8P 23/1 DMX

0.26 mm2

1/0.56 mm

1.4 mm

13 mm

≤ 165 Ω/km

MultiCore 8P 24/7 DMX

0.22 mm2

7/0.60 mm

1.4 mm

15.4 mm

≤ 175 Ω/km

MultiCore 12P 26/7 DMX

0.18 mm2

7/0.48 mm

1.2 mm

22.5 mm

≤ 288 Ω/km

MultiCore 12P 23/1 DMX

0.26 mm2

1/0.56 mm

1.4 mm

15.6 mm

≤ 165 Ω/km

MultiCore 12P 24/7 DMX

0.22 mm2

7/0.60 mm

1.4 mm

17.7 mm

≤ 175 Ω/km

DATA SHEETS
PRODUCT
Download datasheet MultiCore 2P 24/7 DMX PVC
Download datasheet MultiCore 8P 24/7
DMX PVC
Download datasheet MultiCore 4P 24/7
DMX PVC
Download datasheet MultiCore 12P 24/7
DMX PVC
Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.
DATA SHEETS
PRODUCT
Download datasheet MultiCore 2P 26/7 DMX FRNC-C
Download datasheet MultiCore 2P 23/1
DMX PVC
Download datasheet MultiCore 4P 26/7
DMX FRNC-C
Download datasheet MultiCore 4P 23/1
DMX PVC
Download datasheet MultiCore 8P 26/7
DMX FRNC-C
Download datasheet MultiCore 12P 26/7
DMX FRNC-C
Download datasheet MultiCore 12P 23/1
DMX FRNC-C
Download datasheet MultiCore 8P 23/1
DMX FRNC-C
Download detailed datasheets for each cable model. Specifications include electrical parameters, construction, materials, and compliance standards.
Conductor:
This cable uses OFC (Oxygen-Free Copper) conductors, ensuring superior signal transmission and long-term reliability. Oxygen-free copper contains a significantly lower level of oxygen impurities compared to standard copper, resulting in improved conductivity and reduced signal loss over long distances.
Insulation protects the copper conductors from damage, prevents short circuits, and keeps the audio signal clean. Color-coded layers (red/black) ensure correct polarity and easy installation. Depending on the version (PVC or FRNC-C), insulation also provides added flexibility, durability, and fire safety.
The cable features a durable, flexible outer jacket that protects the conductors from mechanical stress, abrasion, and bending. Its smooth surface ensures easy installation, while the material provides long-lasting reliability. Available in a black finish for a clean, professional look; FRNC-C versions offer added flame-retardant and low-smoke safety.
Insulation:
Jacket:
Conductors
Insulation
Jacket
STRUCTURE OF CABLES
Learn more
PVC
FRNC-C
PVC - Polyvinyl Chloride (PVC) is the most common jacket material used in cabling today. PVC is a cost-effective option yet still flexible and rugged enough for many work sites.
FRNC-C - flame-retardant and halogen-free for permanent indoor installationsand complies with the European CPR fire classification Dca.
Certification:
VDE 0472 part 804 class B
IEC 60332-1
Certification:
IEC 60332-3-24
CPR Class: Dca
PRODUCT PICTURES
